Name: 45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty
Brand: SHANAN
SKU: VW-45Z
Price: 1.00 USD
Availability: InStock
Rating: 4.6 (103 reviews)

Product Details

Place of Origin: CHINA

Brand Name: SHANAN

Certification: CE, ISO

Model Number: VW-45Z

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: negotiation

Packaging Details: Box

Delivery Time: 15work days

Payment Terms: T/T

Supply Ability: 100 set/month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                food metal detector, checkweigher, metal separator


Material:	ABS Plastic	Detection Zones:	45/60/90 Zones Accept Customization
Application:	Airports, Custom, Stations	Net Weight:	70 Kgs
Gross Weight:	90 Kgs	Sensitivity Adjustable:	From Level 0 To 300
Power Supply Backup (Option):	Embedded Battery Back-up: 4/8/10 Hours In Optional	Mix Distance Between Two Walk-thru:	0.3 Meters At Low Sensitivity, 0.5meters At High Sensitivity
Warranty:	2 Years

Material:	ABS Plastic
Detection Zones:	45/60/90 Zones Accept Customization
Application:	Airports, Custom, Stations
Net Weight:	70 Kgs
Gross Weight:	90 Kgs
Sensitivity Adjustable:	From Level 0 To 300
Power Supply Backup (Option):	Embedded Battery Back-up: 4/8/10 Hours In Optional
Mix Distance Between Two Walk-thru:	0.3 Meters At Low Sensitivity, 0.5meters At High Sensitivity
Warranty:	2 Years

45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty

45 zone walk through metal detector

Accurate Detection of magnetic, non-magnetic and mixed-alloy metal weapons
High Discrimination and Throughput
Exceptional Immunity to environmental interferences
Unmatched Reliability
Rapid Installation
Visualized single zone sensitivity adjustment
Real multi-zone alarming (Big and small metal can be find at same time)
5 security level presets
30 locations quick settings
100 working frequency bands option

Application

Airports, Custom, Stations
Correctional Facilities
Law Enforcement, Government Building
Schools, Shopping Malls, Hotels, Company
Nuclear Facilities (Security)
Industries (Security)
Public Events, Data Processing Centers

Accurate Detection

Capable of detecting a wide range of threat objects composed of magnetic,non-magnetic metals and mixed alloys
Quick, accurate analysis of all parts of the body of people in transit, from the shoe level to the crossbar
SA600 is a high performance walk-through Multi-Zone Metal Detector which meets all International Security
Standards. A “height on person” display actually indicates, by means of illuminated LED’s, the position of the weapon on the person.
SA600 allows a level of discrimination between significant metal masses, such as the weapons which are to be detected, and personal metal effects
High-sensitivity detection: Unique flying object detection function, accurate alarm of thrown metal objects pass through metal detector door

Specifications:

Key Features

Accurate Detection of magnetic, non-magnetic and mixed-alloy metal weapons
Wide range of threat detection from guns to ½ cutter blade
High Sensitivity and Throughput
Exceptional Immunity to external interferences
High precision bidirectional counter
Random alarm capability programmable from 0% to 20%
Powered by safe low voltage DC
Standard Interfaces: Infrared
Other available interfaces: Ethernet, USB(Optional)

Quality

Continuous self-diagnostic system
Proven reliability
No periodic re-calibration and preventive maintenance required
No scheduled maintenance
Fully digital design

45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty 0 CENTRAL CONTROL

45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty 1 UNIT

Ergonomic and robust design
High visibility 7inch LCD display and programming keyboard
Made of advanced plastics or stainless steel, IP65 weather-proof
Access to the front panel protected by hardware key and three levels of passwords

ALARM SIGNALLING

VISUAL SIGNALS:

Multi-zone display bar for “height on person” localization
2 LED light bars on front door panels
Green metering signals proportional to the mass of the detected target

AUDIO SIGNALS:

16 selectable continuous and pulsed tones
20 selectable sound intensities ranging from 0 to 87 dbA at 1m

45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty 3 TYPE OF

SIGNALLING

VISUAL ZONE INDICATION:

45 zones (60/90 zones accept customization)

PROGRAMMING

Remote via RJ45, Infrared Remote Control Unit or Ethernet 10/100 base T interface, USB port(optional)
SECURITY LEVEL International Standard (IS) command
Local by Control Unit LCD display and keyboard
Programming access protected by user and super-user passwords

45 Detection Zones Walk Through Security Metal Detectors 2 Years Warranty 4 OPERATIONAL

FEATURES

Quick reset time as short as 0.2 seconds for high throughput rate
Very high detection speed (up to 15 m/sec.)

Environmental Data

Power Supply: AC100V~240V 50/60Hz
Power Consumption: 15W
Operating temperature: -20℃~+55℃
Storage temperature: -20°C to +60°C
Relative humidity: 20 to 95% (without condensation)

Size & Weight

Net Weight: 70kgs
Gross Weight: 90kg
Outer frame: 2210mm (h) x 880mm (w) X 600mm (d)
Inner frame: 2010mm (h) X 760mm (w) X 600mm (d)
Packing in one box for each unit
