Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved

Certification
Good quality Belt Conveyor Metal Detectors for sales
Good quality Belt Conveyor Metal Detectors for sales
Customer Reviews
Your food metal detector machine with Spanish Operation system is excellent The operation is easy and senstivity is high I will introduce it to my other food factory friends

—— Miquel Font

Thank you brother, You are a reliable supplier The metal detector and baggage scanner works good

—— Doon

I'm Online Chat Now

Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved

China Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved supplier
Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved supplier Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved supplier

Large Image :  Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved

Product Details:

Place of Origin: China
Brand Name: V FINDER
Certification: CE, ISO9001 , ISO 14000
Model Number: VDF

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: negotiation
Packaging Details: Wooden Box
Delivery Time: 5-7 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 500 units per months
Contact Now
Detailed Product Description
Machine Structure: Full Structure Takes Of Stainless 304 Conveyor Belt Running Speed: 25-30m/min Or Customized Various
Controller Type: Analog / Digital / Touch Screen Load Ability: 5-25kg
Warranty: 12 Months Voltage And Power: 220V 50Hz 90W

High Sensitivity Metal Detector Food Used Conveyor Metal Detector Price


Product advantages:
◆ Mechanism exported from Germany, Dual-channel metal detection system. Coil with a rectangular aperture (no points).
◆ Control system: ADLINE microprocessor controller.
◆ Conveyors: Joint-body PU (polyurethane) Conveyor.
◆ Combined with two-way signal detection circuit technology, liquid crystal display operations in English and visualization.
◆ Has the adjustment function of products effect, such as moist products, products including sugar or salt, they all can make the machine has the signal of metal, which is actually has no metal, so it gets wrong information from the products and affect the detection result. So use this machine with this function can reduce the products’ effect to get better detection result.
◆ With memory and learning function, can store 100kinds of product testing parameters, detecting a wide range of materials.
◆ Completed by the digital signal processing circuit can detect all metal objects, adjusting the simple, stable and reliable.
◆ The combination of DSP and microcontroller data items on the test sample and treatment to improve detection.
◆ Special transport mechanism designed the maxi-Mize sensitivity of metal detectors.
◆ Flexible modular design can be customized according to different requirements.
◆ Mirror stainless steel with open transport system. Easy to clean .
◆ Meet the requirements of IFS and HACCP certification. There are a variety of options excluded institutions depending on the application.
◆ With superior shock interference.


Detail Specification


Model VDF series
Machine specification Normal machine Customized width
(mm)Detection Width 400 300 customized
(mm)Detection Height 100 120 150 200 250 300 350 400
Detection Sensitivity Fe(Φmm) ≥0.6 ≥0.8 ≥1.0 ≥1.2 ≥1.5 ≥2.0 ≥2.5 ≥3.0
Non-Fe(Φmm) ≥1.0 ≥1.2 ≥1.5 ≥2.5 ≥3.0 ≥3.5 ≥4.0 ≥4.5
304Sus(Φmm) ≥1.2 ≥1.5 ≥2.0 ≥2.5 ≥3.0 ≥3.5 ≥4.0 ≥4.5
Alarm and rejector system Automatic stop by alarm and sound or push rod or falling drop
Machine structure Full structure takes of stainless 304
Machine size (mm) L1520mm×W830mm×H1000mm if customized it will according to customized size
Machine weight Around 250KG if customized the weight will different
Voltage and power 220V 50Hz 90W
Load ability 5-25KG conveyor belt running speed :25-30m/min or customized various
Height from the earth 650mm±50mm can customized
Note :Normal size machine have stocks. Unnormal size machine have to customized




Security Metal Detector Machine Adjustable Sensitivity For Food , CE ISO Approved

Metal Detector for bulk products
The versions of metal detectors designed and manufactured by vfinder adapt also to the features of the bulk products. The maximum length of the conveyor belt can reach 1650 mm assuring always the maximum sensibility during the detection.
vfindermetal detectors meet the strictest requirements of functionality, compactness, accuracy and reliability.

Metal Detector for packed products
vfindermetal detectors are also used for packed products (pouches, trays, bags, etc.) and they can detect magnetic and not magnetic metals which can contaminate the industrial products.

vfindermetal detectors are available in different configurations according to:
size and type of product
line operation speed
line space requirements
sorting method used for the products to be rejected

What are the considerations for purchasing a metal detector?

1. Decide what types of metal you need to detect. There are two main categories of metal: ferrous and non-ferrous. Ferrous metals are derived from iron or contain iron. Non-ferrous metals are all others. Take a careful inventory of the types of metal in your operation that could possibly end up in your products.
2. What sizes of metal contaminants do you need to screen for? You need to be practical and realistic with this question because if you specify too much sensitivity, you will get too many false alarms and vice versa.
3. Know the operating environment and the product characteristics – The operating environment includes the temperature and whether water, dust, or chemicals could come in contact with your metal detector, as well as possible electrical fields. Additionally, is the product fresh or frozen, packaged or exposed, scanned individually or in a case? All of these factors will go into the design of a metal detector that will fit your needs the best.
4. Reject System considerations – Most commonly, a pusher or an air blast is used to divert products where metal has been detected. However, you could save space by having the conveyor belt stopped and a warning light activated. Additionally, an optional Lockable Collecting Container prevents unauthorized employees from gaining access to rejected product.

Our Service

24 Hour after- sales service
12 months warranty
Professional technical guidance
Lifelong technical support
