Tunnel Metal Detector , Food Inductrial Metal Detector , HACCP , ISO 9001 , CE Certified

Product Details

Place of Origin: CHINA

Brand Name: SHANAN

Certification: CE, ISO

Model Number: VDF-5005

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: negotiation

Packaging Details: Box

Delivery Time: 15work days

Payment Terms: T/T

Supply Ability: 100 set/month

Get Best Price
Highlight:

conveyor metal detector equipment

,

textile metal detector

Voltage:
110V-220V, 60 HZ
Conveyor Belt Running Speed:
25-30 Meter/min Or Customized
Reject System:
Alarm And Stop, Push Rod, Are Blast, Fall Drop
Machine Weight:
206 Kg
Application:
Food Metal Detection, Industrial Metal Detection
Certificate:
ISO 9001 , CE, HACCP
Voltage:
110V-220V, 60 HZ
Conveyor Belt Running Speed:
25-30 Meter/min Or Customized
Reject System:
Alarm And Stop, Push Rod, Are Blast, Fall Drop
Machine Weight:
206 Kg
Application:
Food Metal Detection, Industrial Metal Detection
Certificate:
ISO 9001 , CE, HACCP
Tunnel Metal Detector , Food Inductrial Metal Detector , HACCP , ISO 9001 , CE Certified



Tunnel Metal Detector , Food Inductrial Metal Detector , HACCP , ISO 9001 , CE Certified


Detect all Types of Metal Including Stainless Steel

Using a tunnel-type metal detector, it is possible to detect all kinds of metal contaminants, including ferrous, non-ferrous and even difficult to detect grades of stainless steel. When integrated with conveyor equipment, tunnel metal detector systems can provide advanced metal detection and rejection solutions for food and non-food processing applications.


Application-Specific Solutions

With a wide range of aperture size ranges and feature sets, Safeline tunnel metal detectors for conveyor systems offer an ideal solution to detect all types of metal for inline food and non-food processing applications.


Stable, Reliable Metal Detection

All METTLER TOLEDO Safeline tunnel metal detectors incorporate robust construction standards to provide stable, reliable, and consistent metal detection performance to detect all types of metal in a wide range of food and non-food processing applications, regardless of the working environment.

Metal Detector Operation

Built-in performance verification routines to comply with retailer codes of practice and food safety regulations are standard in Safeline tunnel metal detectors for conveyor applications. A range of connectivity options and protocols are available to support your data collection and compliance needs.
Technical parameters:


(mm)Detection Height100120150200250300350400
Detection SensitivityFe(Φmm)≥0.6≥0.8≥1.0≥1.2≥1.5≥2.0≥2.5≥3.0
Non-Fe(Φmm)≥1.0≥1.2≥1.5≥2.5≥3.0≥3.5≥4.0≥4.5
304Sus(Φmm)≥1.2≥1.5≥2.0≥2.5≥3.0≥3.5≥4.0≥4.5
Alarm and rejector systemAutomatic stop by alarm and sound or push rod or falling drop
Machine structureFull structure takes of stainless 304



Product advantages:
◆Even product with embedded in metal also can identify a variety of magnetic and non-magnetic metals (such as iron, stainless steel, aluminum, etc.).
◆ Adopts the double circuit signal detection circuit, high sensitivity and strong anti-disturbance ability.
◆ Has the double circuit signal demonstration function. When a metal object passes, the signal light will show different inductance depending on the size of the metal.
◆ Adjustment function by products effect, such as moist products, products including sugar or salt, they all can make the machine has the signal of metal, which is actually has no metal, so it gets wrong information from the products and affect the detection result. So use this machine with this function can reduce the products’ effect to get better detection result.

◆ Can avoid missing detection. When several metal signals are passing, the machine will automatically record the signal amount, so it won’t have missing detection.
◆ Control system: ADLINE microprocessor controller.
◆ Conveyors: Joint-body PU (polyurethane) Conveyor.
◆ Special transport mechanism designed the maximize sensitivity of metal detectors.
◆ Flexible modular design can be customized according to different requirements.
◆ Mirror stainless steel with open transport system. Easy to clean.
◆ Conveyer belt adopts imported white ones safe to food.
◆ Meet the requirements of IFS and HACCP certification. There are a variety of options excluded
institutions depending on the application.

Tunnel Metal Detector , Food Inductrial Metal Detector ,  HACCP , ISO 9001 , CE Certified 0

FAQ


1. Are you manufacturer or trader?
We are manufacturer, we have own factory in Dong Guan, we have independent department for purchasing, producing, processing, testing, packing, storing , and transportation, believe our team is best team in china.
2. Do you sell the accessories for Products ?
Yes. We have Match the parts for our testing equipment. If our machines damages by fire, water flood, earthquakes, unsteady of power and other natural disasters, we are willing supply match parts with lowest price for you.
3.How about the packing for product? Is it easy damaged during transportation?
For light structure products like Gold detector. Hand held metal detector and so on we takes of strong carton box .
For heavy structure products like conveyor belt needle detector. Food metal detector X ray machine .Our packing is Standard Export ploy Wooden Case.
Every prepackage have a plastic bags cover .
4.How about your after-sales policy?
Customer first is our always principle . All of our products normal warranty is 12months. We give necessary back or video guidance for daily problems. If massive products occur big quality problems. Our technical and engineer support overseas service .
5.Do you accept customer Logo and customized ?
we accept kinds of customized and logo of all of our products for customers

Our Service

24 Hour after- sales service
12 months warranty
Professional technical guidance
Lifelong technical support
