Product Details
Place of Origin: CHINA
Brand Name: SHANAN
Certification: CE, ISO
Model Number: SR-001
Document: About Shanan.pdf
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Box
Delivery Time: 15work days
Payment Terms: T/T
Supply Ability: 100 set/month
Product Name: |
Panel And Chain Touch Screen Metal Detector |
Usage: |
Metal Detector For Aquatic Products |
Warranty: |
12 Months |
Type: |
Plate Chain Type |
Product Name: |
Panel And Chain Touch Screen Metal Detector |
Usage: |
Metal Detector For Aquatic Products |
Warranty: |
12 Months |
Type: |
Plate Chain Type |
Scope of application: food, pharmaceutical, chemical, rubber, ice, ice products, toys, eyewear, shoes, leather, knitting, printing and other industries to detect the metal impurities in the production process or raw materials, such as: iron, non-magnetic metal Items ( silver, steel, aluminum, stainless steel and other non-ferrous metals can be detected), improve product safety factor and reduce hazards.
SA-980 series | 3008 | 3012 | 4008 | 4010 | 4012 | 4015 | 4020 | 4025 | |
50 Through width(MM) | 300 | 300 | 400 | 400 | 400 | 400 | 400 | 400 | |
Passing height(MM) | 80 | 120 | 80 | 100 | 120 | 150 | 200 | 250 | |
Belt width(MM) | 270 | 270 | 370 | 370 | 370 | 370 | 370 | 370 | |
standard | FE(ΦMM) | 0.6 | 0.7 | 0.6 | 0.6 | 0.7 | 0.8 | 1 | 1.2 |
Detection | NON-FE(ΦMM) | 0.8 | 1 | 0.8 | 1 | 1 | 1.2 | 1.5 | 1.8 |
Sensitivity | SUS304(ΦMM) | 1 | 1.2 | 1 | 1.2 | 1.2 | 1.5 | 2 | 2.5 |
conveyor length(MM) | 1200 | 1200 | 1500 | 1500 | 1500 | 1500 | 1500 | 1600 | |
Belt height from the ground(MM) | 750±50 can customize | ||||||||
protection level | IP67 | ||||||||
Number of memory products | 100 kinds | ||||||||
Operation method | Touch button input (touch optional) | ||||||||
Conveyor belt material | food grade PVC belt(PU belt) | ||||||||
Alarm mode | Alarm stop ,buzzer alarm or reject mechanism optional | ||||||||
Belt speed | 28m/min | ||||||||
Machine material | Carbon steel paint or stainless steel 304, fit for HACCP, GMP. CAS | ||||||||
Machine weight | About 280KG | ||||||||
Motor | Taiwan high-power motor can transport weight 1-15KG | ||||||||
Power supply | AC220V±10% 50-60HZ (can be customized AC110V or 380V) other optional | ||||||||
Using environment |
Temperature:-18~50°C , relative temperature:30-90°C |
