Product Details
Place of Origin: CHINA
Brand Name: SHANAN
Certification: CE, ISO
Model Number: VMD series
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Box
Delivery Time: 15work days
Payment Terms: T/T
Supply Ability: 100 set/month
Material: |
SUS304 |
Usage: |
Metal Particles Inspections |
Applications: |
Food, Plastic, Medicine,Powder, Granules, Rice |
Detect Range: |
Magnetic And Non Magnetic Materials |
Tube Diameter: |
35 50 70 Mm Optional |
Material: |
SUS304 |
Usage: |
Metal Particles Inspections |
Applications: |
Food, Plastic, Medicine,Powder, Granules, Rice |
Detect Range: |
Magnetic And Non Magnetic Materials |
Tube Diameter: |
35 50 70 Mm Optional |
Needle Detection Tunnel Powder / Sauce Metal Separator / Plastic Needle Metal Separator
|
|
|
|
|
Application:
Advantages:
| 1. Protect production device; |
| 2. Enhance production efficiency; |
| 3. Improve the availability of raw material; |
| 4. Enhance product’s quality; |
| 5. Reduce the expense of maintenance and shuts-down; |
Technical Parameters:
| Model | VF-25 | VF-35 | VF-50 | VF-70 | VF-100 |
|
detecting passage (mm) |
Φ25mm | Φ35mm | Φ50mm | Φ70mm | Φ100mm |
|
Minimum detectable (mm) |
Φ0.2mm | Φ0.3mm | Φ0.5mm | Φ0.7mm | Φ1.0mm |
| Maximum throughput | 250KG/HR | 300-400 KG/HR | 700-800 KG/HR | 1000-1500 KG/HR | 2000-2500 KG/HR |
| Working voltage | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz | 220V/50~60Hz |
| Environment temperature | -10~+80℃ | -10~+80℃ | -10~+80℃ | -10~+80℃ | -10~+80℃ |
|
Disposal time (adjustable) |
0.3-5seconds | 0.3-5seconds | 0.3-5seconds | 0.3-5seconds | 0.3-5seconds |
|
Compressed air |
3~5Bar | 3~5Bar | 3~5Bar | 3~5Bar | 3~5Bar |
|
Features:
|
| 1. Collection of detection coil, controller, separation device. Easy to operate and install. |
| 2. It can save losses of material, because rejection board rapidly rejects unqualified material |
| 3. Low height of installation, easy for integrity; |
| 4. Properties of detection material: dry, good liquidity, no long fiber, no conductivity; |
| 5. Temperature of detection material: less than 80℃;If exceeds 80℃, can choose special components. |
| 6. Controller can be installed around detection place about 10m. |
| 7. Protection level: IP65 |
★Packing details:
Gravity Metal Separator Free Fall Metal Separator for Plastic Industry Package:
1. Plastic wrap moisture
2. Fixed on the bottom of the wooden box
3. Standard export wooden box packaging, reinforcement
|
What is the order process?
|
|
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
|
